Fire Sprinkler Services

Residential Fire Sprinklers & Fire Sprinkler Installation in Seattle, WA - Columbia Fire

Fire Protection Service in Seattle, WA

Sprinklers have been the most efficient form of fire protection for decades. In order to be as safe as possible, all fire sprinkler systems must be tested and maintained in compliance with the requirements and standards of the National Fire Protection Association.

Columbia Fire’s sprinkler test, inspection, maintenance program and confidence testing in Seattle, WA is carried out in accordance with the code requirements set forth in NFPA and the requirements of the local authorities.

Fire Sprinkler Systems: Inspection, Confidence Testing, Maintenance and Repair in Seattle, WA

Fire Sprinkler Systems & Confidence Testing in Seattle, WA - Columbia FireOur qualified and experienced contractors will visually inspect all components unique to the property’s systems and test them at the designated required times. Our contractors will verify that the system appears to be in optimal operating condition and is free of Visible and physical damage. If the systems appear to be damaged or in risk of faulty operation we can provide the necessary maintenance as soon as possible. This includes logging and retention of relevant records.

  • Main drain test
  • Check static pressure
  • Check residual pressure
  • Preaction system
  • Deluge system
  • Control Valves
  • Functional test of all systems

To learn more about all of our services, contact Columbia Fire today!

Foam Water Fire Sprinkler Systems

Foam Water Fire Sprinkler Systems & Confidence Testing in Seattle, WA - Columbia FireFoam water fire sprinkler systems are typically used for hazardous areas. The system uses a mixture of water and low expansion foam concentrate creating a foam spray. With this foam water, flammable liquids can be quickly controlled and diffused.

These types of fire sprinkler systems are the main source of fire suppression in most industrial areas. Building an oxygen free environment, foam water sprinkler systems can be incorporated into nearly any type of system including wet, dry, pre-action or deluge. The correct amount of foam can then be regulated based on the hazardous materials that are intended on being controlled.

Wet Pipe Fire Sprinkler Systems

Wet Pipe Fire Sprinkler Systems & Fire Sprinkler Installation in Seattle, WA - Columbia FireA wet pipe sprinkler system is a sprinkler system employing automatic sprinkler heads attached to a piping system containing water and connected to a water supply so that water discharges immediately from sprinklers opened by heat from a fire.

Each sprinkler is activated individually when it is heated to its design temperature. Most sprinklers discharge approximately 20-25 gallons per minute (gpm), depending on the system design. Sprinklers for special applications are designed to discharge up to 100 gpm.

Dry Pipe Fire Sprinkler Systems

Dry Pipe Fire Sprinkler Systems in Seattle, WA - Columbia FireA dry pipe sprinkler system is a system with automatic sprinkler heads attached to a piping system containing air or nitrogen under pressure. The release of this pressure (as from the opening of a sprinkler) permits the water pressure to open a valve known as a dry pipe valve and the water then flows into the piping system and out of the open sprinkler head.

Dry pipe sprinkler systems are installed in areas where wet pipe systems may be inappropriate such as areas where freezing temperatures might be expected.

Deluge Fire Sprinkler Systems

Deluge Fire Sprinkler Systems & Reliable Fire Sprinklers in Seattle, WA - Columbia FireThe arrangement of deluge fire sprinkler system piping is similar to a wet or dry pipe system with two major differences:

A. Standard sprinklers are used, but they are all open. The activating elements have been removed so that when the control valve is opened water will flow from all of the sprinklers simultaneously and deluge the area with water.

B. The deluge valve is normally closed. The valve is opened by the activation of a separate fire detection system.

Deluge systems are used where large quantities of water are needed quickly to control a fast-developing fire. Deluge valves can be electrically, pneumatically or hydraulically operated.

Pre-action Fire Sprinkler Systems

Pre-action Fire Sprinkler Systems & Fire Protection Service in Seattle, WA - Columbia FireA pre-action sprinkler system is similar to a deluge sprinkler system except the sprinklers are closed. This type system is typically used in areas containing high value equipment or contents and spaces which are highly sensitive to the effects of accidental sprinkler water discharge. The pre-action valve is normally closed and is operated by a separate detection system.

Activation of a fire detector will open the pre-action valve, allowing water to enter the system piping. Water will not flow from the sprinklers until heat activates the operating element in individual sprinklers. Opening of the pre-action valve effectively converts the system to a wet pipe sprinkler system.

In a pre-action system the piping is pressurized with air or nitrogen, monitoring of this air pressure provides a means of supervising the system piping. Loss of the supervisory air pressure in the system piping results in a trouble signal at the alarm panel.
